ECK 3900 PREMIUM
The proof of a winning formula
With the highest standard of performance and efficiency on a functional design. This station skilfully combines quality and features to offer a particularly attractive product and high performance for the management of R134a or HFO1234yf.
Fully automatic A/C station for recovery, recycling and charging for R134a or HFO1234yf
• Wide 5” colour display for an easy, fast and intuitive navigation
• Built-in hybrid feature for the flushing of service hoses and internal circuits. Indispensable for the service on systems with an electric compressor.
• Optional external refrigerant identifier
• Automatic test of the A/C system under pressure with nitrogen or hydrogen/nitrogen mixture
• Management of 1 oil and 1 tracer, both with hermetic refillable containers and with hermetic cartridges
• Automatic purging of non-condensable gases
• Complete database also including commercial and agricultural vehicles
• Status light
OEM Approvals : PSA, Renault, Mitsubishi, Honda, Volvo
India: Volkswagen, Skoda, Toyota, Ford, Renault
FEATURES
Type of refrigerant | HFO1234yf or R134a |
Display | 5'' colour display |
Service valves | Automatic |
Thermal printer | Standard |
Hermetic and refillable containers for oil and dye | Standard 2 + 1 |
Hermetic disposable containers for oil and dye | Option |
Refillable standard containers for oil and dye | Not available |
Hoses | 3 meters |
Data Base Car-Truck-Agri | Standard |
Refrigerant Configuration | Not available |
Hybrid function / electrically driven compressors | Standard |
Pressure test forming gas / nitrogen | Standard |
Gas Identifier / Gas Analyser | Option, Identifier |
Connectivity WIFI | Not available |
Flushing Kit | Option |
Leak check in vacuum | Standard |
Non condensable gas purge | Automatic |
Voltage | 220-240V 50/60 Hz |
Vacuum pump | 100 l/min, vacuum level 0,1 mbar |
Sealed compressor | 1/3 HP |
Recovery speed | 300 g/min in liquid phase |
Tank Scale resolution | 10 gr |
Oil scale resolution | 5 gr |
Working temperature range | 11/49 °C |
Filter system | 1 filter for humidity |
Refrigerant tank | 12 liters (HFO), 22 liters (R134a) |
Bottle heater | Standard |
Dimension / weight | cm 55 x 60 x 110, 90 kg |
Dimension / weight with packaging | cm 70 x 70 x 130, 100 kg |
